If DbContext shows up in every corner of your codebase, you do not have a domain model. You have a thin layer of LINQ wrapped in HTTP.

You see it when:

Minimal API endpoints inject AppDbContext and write queries inline
Domain services take DbContext instead of domain interfaces
Every feature invents its own way to load the same Order or Customer

A tiny change in schema or query behavior then turns into a scavenger hunt across controllers, services, and helpers.

The Repository pattern exists to stop that.

A repository gives you a collection-like gateway for an aggregate. Application code asks the repository for Order or Customer in domain terms. The repository hides SQL, ORM setup, and query shapes. It becomes the one place where you tune how aggregates are loaded and persisted.

In this post, you will see:

What the Repository pattern is in practical .NET terms
A complete IOrderRepository and EfCoreOrderRepository example
Before and after Minimal API snippets that move from DbContext to Repository
When the pattern pays off and when it is just noise

What the Repository Pattern Actually Is

A repository represents a collection of aggregate roots.

Instead of sprinkling queries everywhere, you give your domain a small interface like:

public interface IOrderRepository
{
    Task<Order?> GetByIdAsync(Guid id, CancellationToken cancellationToken = default);
    Task<IReadOnlyList<Order>> FindActiveForCustomerAsync(
        Guid customerId,
        CancellationToken cancellationToken = default);
    Task AddAsync(Order order, CancellationToken cancellationToken = default);
    Task RemoveAsync(Order order, CancellationToken cancellationToken = default);
}

Repository responsibilities:

Hide queries and persistence details
Expose methods that work in domain terms, not in SQL terms
Provide a single, consistent access point for a given aggregate

Fowler places Repository in the object-relational patterns as a way to further isolate domain logic from data access. In practice, that means domain code never sees DbContext or SQL at all. It talks to repositories.

The Order Aggregate: A Quick Domain Model

To make this concrete, start with a small Order aggregate.

public enum OrderStatus
{
    Draft,
    Active,
    Cancelled,
    Completed
}

public class Order
{
    private readonly List<OrderLine> _lines = new();

    private Order(Guid id, Guid customerId)
    {
        Id = id;
        CustomerId = customerId;
        Status = OrderStatus.Draft;
    }

    public Guid Id { get; }
    public Guid CustomerId { get; }
    public OrderStatus Status { get; private set; }
    public IReadOnlyCollection<OrderLine> Lines => _lines.AsReadOnly();
    public decimal TotalAmount => _lines.Sum(l => l.Total);

    public static Order Create(Guid customerId, IEnumerable<OrderLine> lines)
    {
        var order = new Order(Guid.NewGuid(), customerId);

        foreach (var line in lines)
        {
            order.AddLine(line.ProductId, line.Quantity, line.UnitPrice);
        }

        if (!order._lines.Any())
        {
            throw new InvalidOperationException("Order must have at least one line.");
        }

        order.Status = OrderStatus.Active;

        return order;
    }

    public void AddLine(Guid productId, int quantity, decimal unitPrice)
    {
        if (Status != OrderStatus.Draft && Status != OrderStatus.Active)
        {
            throw new InvalidOperationException("Can only change draft or active orders.");
        }

        if (quantity <= 0)
        {
            throw new ArgumentOutOfRangeException(nameof(quantity));
        }

        _lines.Add(new OrderLine(productId, quantity, unitPrice));
    }

    public void Cancel()
    {
        if (Status == OrderStatus.Completed)
        {
            throw new InvalidOperationException("Completed orders cannot be cancelled.");
        }

        Status = OrderStatus.Cancelled;
    }
}

public class OrderLine
{
    public OrderLine(Guid productId, int quantity, decimal unitPrice)
    {
        ArgumentOutOfRangeException.ThrowIfNegativeOrZero(quantity);

        ProductId = productId;
        Quantity = quantity;
        UnitPrice = unitPrice;
    }

    public Guid ProductId { get; }
    public int Quantity { get; }
    public decimal UnitPrice { get; private set; }
    public decimal Total => Quantity * UnitPrice;
}

Note what is not there:

No DbContext
No mapping attributes
No SQL knowledge

Order cares about behavior. Persistence will live somewhere else.

Before: Minimal API Endpoints With `DbContext` Everywhere

Here is a typical Minimal API endpoint that cancels an order directly using AppDbContext.

app.MapPost("/orders/{id:guid}/cancel", async (
    Guid id,
    AppDbContext db,
    CancellationToken ct) =>
{
    var orderEntity = await db.Orders
        .Include(o => o.Lines)
        .SingleOrDefaultAsync(o => o.Id == id, ct);

    if (orderEntity is null)
    {
        return Results.NotFound();
    }

    if (orderEntity.Status == OrderStatus.Completed)
    {
        return Results.BadRequest("Completed orders cannot be cancelled.");
    }

    orderEntity.Status = OrderStatus.Cancelled;

    await db.SaveChangesAsync(ct);

    return Results.Ok(new { orderEntity.Id, orderEntity.Status });
});

A few problems:

Endpoint knows which includes it needs
Endpoint knows about status rules
Endpoint is responsible for translating domain rules into property changes
If the cancellation rule changes, you touch this endpoint and any other place that cancels orders

Now imagine you have:

Another endpoint that cancels from an admin UI
A background worker that cancels expired orders

Each one might be implementing its own variation of “how cancellation works.”

After: Minimal API Endpoints Using `IOrderRepository`

Now introduce a repository and let the domain enforce its own rules.

First, the repository interface:

public interface IOrderRepository
{
    Task<Order?> GetByIdAsync(Guid id, CancellationToken cancellationToken = default);
    Task<IReadOnlyList<Order>> FindActiveForCustomerAsync(
        Guid customerId,
        CancellationToken cancellationToken = default);
    Task AddAsync(Order order, CancellationToken cancellationToken = default);
    Task RemoveAsync(Order order, CancellationToken cancellationToken = default);
}

Then the endpoint was refactored to use it:

app.MapPost("/orders/{id:guid}/cancel", async (
    Guid id,
    IOrderRepository orders,
    CancellationToken ct) =>
{
    var order = await orders.GetByIdAsync(id, ct);
    if (order is null)
    {
        return Results.NotFound();
    }

    try
    {
        order.Cancel();
    }
    catch (InvalidOperationException ex)
    {
        return Results.BadRequest(ex.Message);
    }

    await orders.AddAsync(order, ct); // in many setups, tracked aggregates are updated automatically
    return Results.Ok(new { order.Id, order.Status });
});

Now:

The endpoint does not know how to query an order
The endpoint does not encode the cancellation rule
The endpoint calls order.Cancel(), and the domain decides whether that is allowed

Cancellation logic lives in one place: Order.Cancel.

You can reuse it from:

Other endpoints
A background worker
A scheduled job

without duplicating rule logic.

Implementing `IOrderRepository` With EF Core

You need a concrete implementation in infrastructure. There are two common styles:

Domain entities are also EF Core entities
Domain entities are separate from EF Core entities, and you map between them

To keep the example focused, assume Order and OrderLine are EF Core entities as shown.

public class AppDbContext : DbContext
{
    public DbSet<Order> Orders => Set<Order>();

    public AppDbContext(DbContextOptions<AppDbContext> options)
        : base(options)
    {
    }

    protected override void OnModelCreating(ModelBuilder modelBuilder)
    {
        var order = modelBuilder.Entity<Order>();
        order.HasKey(o => o.Id);
        order.Property(o => o.Status)
             .HasConversion<string>();

        var line = modelBuilder.Entity<OrderLine>();
        line.HasKey(l => new { l.ProductId, l.Quantity, l.UnitPrice });

        order.HasMany(typeof(OrderLine), "_lines");
    }
}

Repository implementation:

public class EfCoreOrderRepository : IOrderRepository
{
    private readonly AppDbContext _dbContext;

    public EfCoreOrderRepository(AppDbContext dbContext)
    {
        _dbContext = dbContext;
    }

    public async Task<Order?> GetByIdAsync(
        Guid id,
        CancellationToken cancellationToken = default)
    {
        return await _dbContext.Orders
            .Include(o => o.Lines)
            .SingleOrDefaultAsync(o => o.Id == id, cancellationToken);
    }

    public async Task<IReadOnlyList<Order>> FindActiveForCustomerAsync(
        Guid customerId,
        CancellationToken cancellationToken = default)
    {
        return await _dbContext.Orders
            .Include(o => o.Lines)
            .Where(o => o.CustomerId == customerId && o.Status == OrderStatus.Active)
            .ToListAsync(cancellationToken);
    }

    public Task AddAsync(Order order, CancellationToken cancellationToken = default)
    {
        // This covers both new and tracked aggregates depending on how you attach them
        _dbContext.Orders.Update(order);
        return Task.CompletedTask;
    }

    public Task RemoveAsync(Order order, CancellationToken cancellationToken = default)
    {
        _dbContext.Orders.Remove(order);
        return Task.CompletedTask;
    }
}

Wire it up in Program.cs:

builder.Services.AddDbContext<AppDbContext>(options =>
{
    options.UseSqlServer(builder.Configuration.GetConnectionString("DefaultConnection"));
});

builder.Services.AddScoped<IOrderRepository, EfCoreOrderRepository>();

From this point forward, everything outside the infrastructure talks only to IOrderRepository.

Before vs After: Querying Orders For A Customer

One more example: listing a customer’s active orders.

Before: Endpoint Owns The Query

app.MapGet("/customers/{customerId:guid}/orders/active", async (
    Guid customerId,
    AppDbContext db,
    CancellationToken ct) =>
{
    var orders = await db.Orders
        .Include(o => o.Lines)
        .Where(o => o.CustomerId == customerId && o.Status == OrderStatus.Active)
        .Select(o => new
        {
            o.Id,
            o.Status,
            Total = o.Lines.Sum(l => l.Total)
        })
        .ToListAsync(ct);

    return Results.Ok(orders);
});

The endpoint knows:

How to filter by status
That lines should be included
That total should be computed by summing line totals

Any other feature that needs “active orders for customer” will reinvent this.

After: Endpoint Delegates To `FindActiveForCustomerAsync`

app.MapGet("/customers/{customerId:guid}/orders/active", async (
    Guid customerId,
    IOrderRepository orders,
    CancellationToken ct) =>
{
    var activeOrders = await orders.FindActiveForCustomerAsync(customerId, ct);

    var response = activeOrders.Select(o => new
    {
        o.Id,
        o.Status,
        Total = o.TotalAmount
    });

    return Results.Ok(response);
});

Now the rules about what “active orders” mean, and how to load them efficiently, live in the repository. The endpoint just shapes the response.

If you later decide:

Active should exclude certain edge cases
Orders should always be loaded with a new related entity
Performance requires changing Include strategy

you change it in one place.

Repository vs Data Mapper vs EF Core

You may ask: if EF Core is already a mapper, why add repositories?

Think in layers:

EF Core is a Data Mapper implementation. It maps objects to tables.
A Repository is a domain-facing facade over that mapper. It hides EF specifics and speaks domain language.

Comparisons:

Direct EF Core in the domain or endpoints
- Quick to start
- Strong coupling to ORM and database schema
- Queries scattered everywhere
Data Mapper only
- Explicit mapping code between domain objects and records
- Still no consistent collection-like abstraction
Repository on top
- Aggregates are retrieved and persisted through a single gateway
- Domain and application services work in terms of Order and Customer, not DbSet<Order>

You can use EF Core directly in repository implementations. The repository makes sure the rest of your code does not care.

When To Use The Repository Pattern

A repository is not a rule. It is a tradeoff. It pays off in specific situations.

1. Central Aggregates Used Everywhere

If an aggregate like Order appears in:

Checkout flows
Customer dashboards
Admin tools
Background processes

then you want one definitive place that controls:

How it is loaded
Which relationships are included
How archived or soft-deleted data is filtered

That is what a repository is for.

2. You Want Consistent Access Rules

You may have cross-cutting rules such as:

All queries should filter out soft-deleted records
All active orders must eagerly load lines to avoid N+1 issues

Repositories let you express these once. Without them, you rely on every caller remembering to apply the same filters and includes.

3. Multiple Stores Or Read Models

If there is any chance you will:

Add a read-optimized store
Introduce caching for certain aggregates
Split reads and writes across different data sources

a repository interface gives you the seam you need. Implement it differently for different scenarios; the rest of the system continues to call the same methods.

4. Rich Domain Model With Real Behavior

If you invested in domain objects that encapsulate rules, you want those objects to be loaded and persisted in a disciplined way. Repositories are the natural companion to a Domain Model and Service Layer.

When Not To Use The Repository Pattern

Sometimes a repository is just noise.

1. Tiny CRUD Applications

If your app:

Has a handful of endpoints
Mirrors the database schema directly
Contains almost no business logic

then a full Repository layer might slow you down more than it helps. A thin service over DbContext or even direct endpoint queries can be acceptable.

2. One-Off Tools And Scripts

For:

Migration utilities
Maintenance scripts
Quick internal data tools

introducing repositories and interfaces often adds ceremony without long-term benefit. These tools are not your core domain.

3. Heavy Reporting And Projections

Complex read queries that:

Join across multiple bounded contexts
Aggregate data for dashboards and analytics

may be better served by dedicated query handlers that return projections rather than aggregates. Forcing them through an aggregate repository can make designs confusing.

4. Generic `IRepository<T>` Everywhere

The most common anti-pattern:

public interface IRepository<T>
{
    Task<T?> GetByIdAsync(Guid id);
    Task AddAsync(T entity);
    Task RemoveAsync(T entity);
}

This encourages:

Anemic domain models with generic operations only
No domain-specific methods like FindActiveForCustomerAsync
A false sense of abstraction without meaningful domain language

If you go with repositories, make them specific to aggregates and name methods in domain terms.

Introducing Repositories Into An Existing App

You do not have to refactor everything.

A pragmatic path:

Pick one high-value aggregate, such as Order.
Design a repository interface that expresses what callers actually need, in domain terms.
Implement it once using your existing data access code.
Update a few key endpoints or services to depend on the repository instead of DbContext.
Observe how much duplication and cognitive load disappears around that aggregate.

If it feels cleaner and safer, continue with other aggregates. If it feels like ceremony for your situation, stop there.

Closing Thoughts

A repository is not a magical pattern. It is a disciplined way to say:

“All access to this aggregate goes through this one door.”

In ASP.NET Core Minimal APIs, that single decision shifts your structure:

Endpoints become thinner, focused on HTTP concerns
Domain objects hold rules and behavior
Repositories become the single source of truth for how aggregates are loaded and persisted

The next time you reach for DbContext inside an endpoint or domain service, ask yourself a simple question:

Should this code really know how orders are stored, or should it just ask for an Order and let a repository handle the rest?

Tags: .NET C# dotnet patterns programming
